PESU - Polyethersulfone

Polyethersulfone (PESU), is a high-performance material with a temperature profile that is unique among engineering thermoplastics a long-term temperature resistance up to 180°C.

PESU is used in apparatus engineering and in the electrical and electronics fields in the automotive and transportation sectors, in the food and household sectors as a substitute for glass, metal, ceramic, and porcelain.


Download the data sheet



Main 3D printing parameters

Advised nozzles Brass 0.25 | 0.4 | 0.6 | 0.8 | 1.0 | 1.2 mm
Printing temperatures 340 - 380°C
Buildplate substrate HT buildplate
Builplate temperature 110 - 150°C

Typical properties

Tensile strength at break
85 MPa
Charpy notched impact strength
6.5 J/m2
Tensile modulus
2 650 MPa
Elongation at break
6,9%

Typical properties; not to be construed as specifications.
DIN EN ISO 527-2 & ISO 179/1eA.

Let’s dive into the possibilities offered by PAM


From pellets to object, PAM technology offers the most direct process to high performances end-parts.
